SCULPFUN Engraving machine camera,120° Lens 400 5MP 120° Lens * 400mm Area Compatible CAM500 Camera 5MP S6/S6 /S9/S10/S30 S30 Lens 400 * 400 x 400mm S9 / S10 / S9 / Suitable S6 / S6 / S6

SCULPFUN CAM500 Camera 5MP Pixel 120° Wide-angle Lens with 400*400mm Working Area Suitable for Sculpfun S6/S6 pro/S9/S10/S30 and S30 Ultra series Engravers Compatible with win7/win10/win11/macSystem and Other Engraving Machine Modes D1PRO/ falcon2/LM2 PRO S2/20PRO 20S/55/JL3/ 3 MAX V2: This engraving camera has a 120° wide-angle lens with a working area of 400*400mm. It can record the entire creation process of works through camera time-lapse shooting, easy for you to share the creative process with friends. And also makes the engraving and cutting visible and observable.With the Sculpfun CAM500 Lightburn camera, you can move the pattern onto a certain position of the material through the lightburn software interface. After the setting is complete, the machine will engrave the pattern at that position.CAM500 camera module can identify and extract the patterns from the surface of objects such as T-shirt patterns, children's hand-drawn patterns or other simple designs and form engraving vector files, which is super convenient for getting vector files quickly.The SCULPFUN CAM500 camera is perfectly fit with the CAM function of the Lightburn software, which can identify the position of engraving objects via the camera, with a positioning deviation of less than 1mm.2 fixation structures, T-shaped fixation clamp and U-shaped fixation clamp. T-shaped fixation clamp is suitable for SCULPFUN machine including S6,S6 pro,S9, S10, S30/S30 Ultra series and almost all engraving machines with structure. Please note that the additional purchased area expansion kit is not applicable.U-shaped fixation clamp is suitable for U-shaped beam machines.Other applicable : D1PRO, falcon2, LM2 PRO S2, 20PRO 20S, 55, JL3, 3 MAX V2.Through the Lightburn camera, you can add multiple engraving objects and complete the different independent tasks at one time, without the need to preview the positioning of each engraving material. The will automatically find the engraving objects one by one and work on them, which improves the working efficiency.This industrial assist camera is specially designed for engraving machines, which fully matches with the lightburn software. With a true high-definition 5MP, this camera can capture clearer images and identify more accurate positioning. Specification: Product Model: SCULPFUN CAM500 Compatible System: win7/win10/win11/mac Notice: For better product usage experience, we recommend to use with the system win7 later version Mount Material: Aluminum Optimal Working Area: 400*400mm Product Size Horizontal Rod and Vertical Rod are the same: 400*15*20mm Notice: please allow the variations due to manual measurement! Recommended Height from the Camera to the Engraving Position: 325mm Camera Parameter: Color Image Sensor: 1/4-inch CMOS Maximum Resolution: 2592*1944 Fixed Focus Distance: 325mm Aperture: F2.4 Focal Length: 1.79mm Pixel Size: 1.4um*1.4um Pixel: 5MP Focusing Mode: Fixed Focus USB Interface: USB 2.0 Viewing Angle Width: 120° Package Weight: 0.8KG/28.2oz Package Size: 462x180x55mm/18.1x7x2.1in Note:The recommended height from the camera to the engraving position is 325mm. With the camera well aligned, please make the objects as close to the center of the camera as possible, within the 400*400mm working area. The precision will be decreased as the engraving objects are moved away from the camera center.） Packing List: 4 x Basswood Plywood 1 x U-shaped Clamp Assembly 1 x User Manual 1 x T-shaped Clamp Assembly 1 x Camera Vertical Rod Assembly 1 x Camera Slider Rod Connector 1 x Screw Bag 1 x Soft Ruler 3 x A5 Size Image Calibration Paper 1 x Camera Horizontal Rod Assembly

• 2. Precise Positioning: The SCULPFUN CAM500 camera is perfectly fit with the CAM function of the Lightburn software, which can identify the position of engraving objects via the camera, with a positioning deviation of less than 1mm.
• 3. Engraving Position Controlling: With the Sculpfun CAM500 Lightburn camera, you can move the pattern onto a certain position of the material through the lightburn software interface. After the setting is complete, the laser machine will engrave the pattern at that position.
• 5. Batch Engraving: Through the laser Lightburn camera, you can add multiple engraving objects and complete the different independent tasks at one time, without the need to preview the positioning of each engraving material. The laser will automatically find the engraving objects one by one and work on them, which improves the working efficiency.
• 6. HD Video Recording: This laser engraving camera has a 120° wide-angle lens with a working area of 400*400mm. It can record the entire creation process of works through camera time-lapse shooting, easy for you to share the creative process with friends. And also makes the engraving and cutting visible and observable.
• 7. High Adaptability: 2 fixation structures, T-shaped fixation clamp and U-shaped fixation clamp. T-shaped fixation clamp is suitable for SCULPFUN machine models including S6,S6 pro,S9, S10, S30/S30 Ultra series and almost all engraving machines with V-slot structure. Please note that the additional purchased area expansion kit is not applicable. U-shaped fixation clamp is suitable for U-shaped beam machines. Other applicable models: D1PRO, falcon2, LM2 PRO S2, 20PRO 20S, 55, JL3, 3 MAX V2.
